เตาเผาแก๊สแบบ Muffle อุณหภูมิสูง 1400 องศาเซลเซียส

ผู้ติดต่อ: David Yuan

เบอร์ติดต่อ:18659217588

EmailEmail: David@batterymaking.com

whatsapp: 86 18659217588

  • ยี่ห้อ :

    TMAX
  • แบบอย่าง:

    TMAX-1400atmosphere
  • วิธีการชำระเงิน :

    L/C, Western Union, Paypal
  • ใบรับรอง :

    CE, ROHS
  • เวลาการจัดส่งสินค้า :

    5 วัน
  • ข้อมูลผลิตภัณฑ์

1400C High Temperature Atmosphere Gas Muffle Furnace



Detailed technical parameters


Power

3KW

5KW

7KW

9KW

13KW

18KW

Chamber size(mm)

160X150X150

200X200X200

300X200X200

300X250X250

400X300X300

500X400X400

Boundary dimension(mm)

550X515X905

590X555X995

590X655X985

640X655X1035

690X715X1125

834X902X1335

Supply voltage

220V

                  380V

Phase

Single phase

single  phase

                 three phase

Heating element

                                               silicon carbide rod

Control mode

UAV program temperature control instrument

1, 30-stage program temperature control  intelligent PID adjustment.

2. With over-temperature protection, the  electric furnace heating circuit is automatically cut off when the  temperature is over-temperature or broken. (When the electric furnace  temperature exceeds 1420 degrees or the thermocouple is blown, the AC relay  on the main circuit will be automatically disconnected and the main circuit  will be disconnected. The ON light on the panel is off, the OFF light is on,  and the limited protection electric furnace).

3, with 485 communication interface (standard  when purchasing software)

4, with power-off protection function, that is,  when the power is turned on after the power is turned off, the program does  not start from the starting temperature, but the furnace temperature rises  from the time of power failure.

5, the meter has the function of temperature  self-tuning


(you need to pay extra for the replacement of imported  instruments, optional)



FP93 temperature controller            European  instrument                Touch screen  instrument

(shimaden, Japan)

Furnace material

Type 1600 alumina  polycrystalline fibre. Furnace material imported from Japan is available  (additional charge is required for the selection of imported furnace  material)

Control accuracy

                                               +/- 1℃

Trigger

                                         Phase-shifted trigger

Electric appliance

                                          Zhejiang chint

Silicon controlled

                                       106/16ESEMIKRON

Maximum temperature

                                                      1400℃

Rated temperature

                                                       1350℃

Heating rate

                    ≤20℃/ Min(it  can be modified as required)

Recommended rate of  temperature rise

                                                      ≤10℃/ Min

Thermocouple Type

                                                         S type

Identification

                                                             CE

Peripheral surface temperature

                                                            ≤45℃



Maximum operating temperature in all atmospheres

Gas atmosphere

Maximum operating  temperature in all atmospheres

air

1400

vacuum

900-1100

Nitrogen gas

1270

Hydrogen gas

1100

Hydrocarbon gas

1150

Argon

1300



 Tmax CE

 TMAX Partner

CVD furnace


tube furnace


muffle furnace



1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

3 Responsible for the damage during the shipping process, will change the damage part for you for free.



TMAXCN Cooperative Brand and TMAXCN Group Employees
